More PCB Connector Systems
Series 30 | Micromodul™ connectors, pitch 1.27 mm
For cable-to-board connections with flat cables, where space is at a premium. Plugs and solder-in connectors in insulation displacement technology, tab headers for THT and SMT soldering. For signal and low load currents up to 1.2 A, pitch 1.27 mm (.050").
No product found with this configuration.
MICAL
Micromodul™ solder-in connector, insulation displacement technology (IDT), solder contacts dual row staggered
MICALD
Micromodul™ solder-in connector, insulation displacement technology (IDT), solder contacts dual row parallel
MICA
Micromodul™ connector for indirect mating, insulation displacement technology (IDT), with lock, loose
MICA VP3
Micromodul™ connector for indirect mating, insulation displacement technology (IDT), with lock MICA: loose, on reel
302299
Micromodul™ connector for direct mating, insulation displacement technology (IDT), with locking on printed circuit board by means of locking hooks and toes, with closed sides
MICS
Micromodul™ tab header, upright, with retaining hooks, solder contacts dual row staggered
MICS-D
Micromodul™ tab header, upright, without retaining hooks, solder contacts dual row parallel
MICSW
Micromodul™ tab header, angular, solder contacts dual row staggered
MICS/SMD
Micromodul™ tab header, upright, in surface mount technology (SMT), solder contacts dual row staggered, with press-fit spigots, in bulk, with retaining hooks
MICS/SMD RP
Micromodul™ tab header, upright, in surface mount technology (SMT), solder contacts dual row staggered, with press-fit spigots, on reel, with pick-and-place top
AZ30
Pull-off tongs for Micromodul™ connectors
Series 73 | SmartSKEDD™ direct connectors, pitch 2.5/5.0 mm
Direct mating with SKEDD technology, for cable-to-board connections in insulation displacement technology, solderless and reversible. Keying avoids mismating. For signal and low load currents up to 4 A, pitch 2.5 mm and 5.0 mm (.098" and .197").
No product found with this configuration.
733520
SmartSKEDD direct connector, insulation displacement technology (IDT), with keying pins, positioning spigot and locking on the printed circuit board
733530
SmartSKEDD direct connector, insulation displacement technology (IDT), with keying pins, positioning spigot and locking on the printed circuit board
733500
SmartSKEDD direct connector, insulation displacement technology (IDT), with keying pins, positioning spigot and double locking on the printed circuit board
733510
SmartSKEDD direct connector, insulation displacement technology (IDT), with keying pins, positioning spigot and double locking on the printed circuit board
Series 72 | Press-fit interconnect solutions
For cable-to-board and board-to-board connections in automotive and beyond. Solderless press-fit connections as per IEC/EN/DIN 60352-5.
Series 31 | Minimodul™ connectors, pitch 2.5 mm
For cable-to-board connections. Easy harnessing with crimp technology. Especially suitable for low and middle-volume production. For signal and low load currents up to 5 A. Pitch 2.5 mm (.098").
No product found with this configuration.
3114
Empty Minimodul™ housing for reception of crimp contacts, for indirect mating
3111 01 L
Minimodul™ crimp contact, in bulk
3111 01 G
Minimodul™ crimp contact, on reel
3111 03 L
Minimodul™ crimp contact, in bulk
3111 03 G
Minimodul™ crimp contact, on reel
2,5 MSF/O
Minimodul™ pin header, upright, solder contacts single row
2,5 MSFQ/O
Minimodul™ pin header, upright, solder contacts dual row staggered
2,5 MSF
Minimodul™ pin header, upright, with locking latch, solder contacts single row
2,5 MSFQ
Minimodul™ pin header, upright, with locking latch, solder contacts dual row staggered
2,5 MSFW/O
Minimodul™ pin header, angular, solder contacts single row
2,5 MSFW
Minimodul™ pin header, angular, with locking latch, solder contacts single row
Obsolete
2,5 MS
Minimodul™ pin header
Series 38 | Multimodul™ connectors, pitch 2.5 mm
Connectors with keying option in crimp technology. Suitable for single leads and flat cables. For cable-to-board and board-to-board connections. Especially suitable for middle and high-volume production. For signal and low load currents up to 3 A, pitch 2.5 mm (.098").
No product found with this configuration.
3823
Empty Multimodul™ housing for reception of crimp contacts, for indirect mating
3111 01 L
Multimodul™ crimp contact, in bulk
3111 01 G
Multimodul™ crimp contact, on reel
3111 03 L
Multimodul™ crimp contact, in bulk
3111 03 G
Multimodul™ crimp contact, on reel
3850
Multimodul™ pin header, upright, with locking latch, with retaining hooks
3853
Multimodul™ pin header, angular, with locking latch, with retaining hooks
8385 A 01
Double Multimodul™ chassis pin header as feed-through connector, with locking latches and gasket
Phasing out
3851
Multimodul™ pin header, upright, with retaining hooks
Phasing out
3852
Multimodul™ pin header, upright, with locking latch
Phasing out
3855
Multimodul™ pin header, upright, with locking latch, with retaining hooks and cut-outs for 3801
Phasing out
3800
Multimodul™ socket board, angular, with retaining hooks
Phasing out
3801
Multimodul™ socket board, angular, with retaining hooks, with locking nose
Series 41 | Shorting links, pitch 2.5/2.54 mm
For direkt connection of two contact pins, i.e. as a jumper for alternative circuitry. Shorting links are suitable for pin headers with pitch 2.5 mm and 2.54 mm (.098" and .100"). For signal and load currents up to 5 A.
Series 51 | Direct connectors for printed circuit boards, pitch 2.54/5.08 mm
Sockets boards for direct mating. For signal and load currents up to 5 A, pitch 2.54 mm and 5.08 mm (.100", .200").
Series 52 | Direct connectors with screw clamps, for insert cards, pitch 5.0 mm
Sockets boards for insert cards, with screw clamps for cable-to-board connections. With accessory keying inserts, mounting and guide flanges. For signal and load currents up to 5 A, pitch 5.0 mm (.197").
Series 61 | Screw terminal blocks, pitch 3.5/5.0/10.0 mm
For all cable-to-board connections relevant to maintainance. Lead sections up to 4.0 mm². For signal and load currents up to 15 A, pitch 3.5 mm, 5.0 mm and 10.0 mm (.138", .197" and .394").
No product found with this configuration.
KRMC
Micro screw terminal block, clamp with wire protector, upright version, consecutive placement without loss of pitch
KRESS
Screw terminal block, clamp with wire protector, upright version, consecutive placement without loss of pitch
Obsolete
KRES
Screw terminal block, clamp with wire protector, upright version, with test hole, consecutive placement without loss of pitch
KRESW
Screw terminal block, clamp with wire protector, 45° angle version, with test hole, stringable without loss of pitch
KRESL
Screw terminal block, clamp with wire protector, right angle version, with test hole, consecutive placement without loss of pitch
KRM
Screw terminal block, clamp with wire protector, upright version, consecutive placement without loss of pitch
6320
Miniature screw terminal block, with lift clamp without protection against misplacing, upright version, with test hole, consecutive placement without loss of pitch
6322
Miniature screw terminal block, with lift clamp without protection against misplacing, 35° angle version, with test hole, consecutive placement without loss of pitch
6324
Miniature screw terminal block, with lift clamp without protection against misplacing, right angle version, with test hole, consecutive placement without loss of pitch
KRE
Screw terminal block, with lift clamp with protection against misplacing, upright version, consecutive placement without loss of pitch
KREG
Screw terminal block, with lift clamp with protection against misplacing, with stronger screw, upright version, consecutive placement without loss of pitch
KRESS 03/02 - 07/04
Screw terminal block, clamp with wire protector, upright version
KRESL 03/02 - 05/03
Screw terminal block, clamp with wire protector, right angle version
KREN
Screw terminal block for mains supply, with lift clamp with protection against misplacing, upright version
KRENG
Screw terminal block for mains supply, with lift clamp with protection against misplacing, with stronger screw, upright version
Series 65 | Pluggable screw terminal blocks on socket boards, pitch 5.0 mm
Space-saving solution of pluggable screw termination, no mismating, with locking. Lead sections up to 4.0 mm². For signal and load currents up to 10 A, pitch 5.0 mm (.197").
No product found with this configuration.
KS
Pluggable screw terminal block, clamp with wire protection, consecutive placement without loss of pitch, without side walls
KSC
Pluggable screw terminal block, clamp with wire protection,
consecutive placement without loss of pitch, with side walls
KB
Socket board, upright, solder pins single row, consecutive placement without loss of pitch
KBQ
Socket board, upright, solder pins dual row staggered, consecutive placement without loss of pitch
KBWO
Socket board, angular, solder pins single row, consecutive placement without loss of pitch
KBW
Socket board, angular, solder pins single row, with retaining hooks for printed circuit board edge, consecutive placement without loss of pitch
Series 67 | Pluggable terminal blocks on pin headers, pitch 5.08 mm
Connectors in insulation displacement termination (IDT) for automated harnessing. Compatible mating with many products in the market. For signal and load currents up to 6 A, pitch 5.08 mm (.200").
