更多适用PCB连接器

系列 30 | Micromodul™连接器，间距1.27mm

适用于扁平线缆的线对板连接，当对空间有严格要求时可选。使用绝缘刺破技术的插头和焊入式连接器，及使用于THT或SMT焊接的插座。可用于信号和最高1.2 A的低负载电流，间距为1.27mm。

注意 RoHS/REACH

未找到该配置的产品。

MICAL

Micromodul™ solder-in connector, insulation displacement technology (IDT), solder contacts dual row staggered

MICALD

Micromodul™ solder-in connector, insulation displacement technology (IDT), solder contacts dual row parallel

MICA

Micromodul™ connector for indirect mating, insulation displacement technology (IDT), with lock, loose

MICA VP3

Micromodul™ connector for indirect mating, insulation displacement technology (IDT), with lock MICA: loose, on reel

302299

Micromodul™ connector for direct mating, insulation displacement technology (IDT), with locking on printed circuit board by means of locking hooks and toes, with closed sides

MICS

Micromodul™ tab header, upright, with retaining hooks, solder contacts dual row staggered

MICS-D

Micromodul™ tab header, upright, without retaining hooks, solder contacts dual row parallel

MICSW

Micromodul™ tab header, angular, solder contacts dual row staggered

MICS/SMD

Micromodul™ tab header, upright, in surface mount technology (SMT), solder contacts dual row staggered, with press-fit spigots, in bulk, with retaining hooks

MICS/SMD RP

Micromodul™ tab header, upright, in surface mount technology (SMT), solder contacts dual row staggered, with press-fit spigots, on reel, with pick-and-place top

AZ30

Pull-off tongs for Micromodul™ connectors

系列 73 | SmartSKEDD™连接器，间距2.5/5.0mm

直接连接运用SKEDD技术，使用绝缘刺破技术的线对板。
的键控设计，避免错配。可用于信号和最高4A的低负载电流，间距为2.5mm和5.0mm。

注意 RoHS/REACH

未找到该配置的产品。

733520

SmartSKEDD direct connector, insulation dis­place­ment technology (IDT), with keying pins, positioning spigot and locking on the printed circuit board
contact pitch 2.5 mm

733530

SmartSKEDD direct connector, insulation dis­place­ment technology (IDT), with keying pins, positioning spigot and locking on the printed circuit board
contact pitch 5.0 mm

733500

SmartSKEDD direct connector, insulation dis­place­ment technology (IDT), with keying pins, positioning spigot and double locking on the printed circuit board
contact pitch 2.5 mm

733510

SmartSKEDD direct connector, insulation dis­place­ment technology (IDT), with keying pins, positioning spigot and double locking on the printed circuit board
contact pitch 5.0 mm

系列 72 | 压接（Press-fit）互联解决方案

用于汽车等的线对板和板对板连接，符合IEC/EN/DIN 60352-5的无焊压接连接。

注意 RoHS/REACH

未找到该配置的产品。

7200

Press-fit contact 0.6 for customer-specific interconnect solutions, according to internal test specifications as per automotive requirements on the basis of IEC 60352-5

7201

Press-fit contact 0.8 for customer-specific interconnect solutions, according to internal test specifications as per automotive requirements on the basis of IEC 60352-5

系列 31 | Minimodul™连接器，间距2.5mm

适用于线对板连接。易于采用压接技术进行单线和扁平线缆组装。特别适用于低和中批量生产。可用于信号和最高5A的低负载电流，间距为2.50mm。

注意 RoHS/REACH

未找到该配置的产品。

3114

Empty Minimodul™ housing for reception of crimp contacts, for indirect mating

3111 01 L

Minimodul™ crimp contact, in bulk

3111 01 G

Minimodul™ crimp contact, on reel

3111 03 L

Minimodul™ crimp contact, in bulk

3111 03 G

Minimodul™ crimp contact, on reel

2,5 MSF/O

Minimodul™ pin header, upright, solder contacts single row

2,5 MSFQ/O

Minimodul™ pin header, upright, solder contacts dual row staggered

2,5 MSF

Minimodul™ pin header, upright, with locking latch, solder contacts single row

2,5 MSFQ

Minimodul™ pin header, upright, with locking latch, solder contacts dual row staggered

2,5 MSFW/O

Minimodul™ pin header, angular, solder contacts single row

2,5 MSFW

Minimodul™ pin header, angular, with locking latch, solder contacts single row

已淘汰

2,5 MS

Minimodul™ pin header

系列 38 | Multimodul™连接器，间距2.5mm

采用压接技术的连接器。键控设计，避免错配。适用于单引线和扁平电缆。用于电缆对板和板对板连接。特别适合中、大批量生产。适用于信号和低负载电流高达 3 A，间距 2.5 毫米。

注意 RoHS/REACH

未找到该配置的产品。

3823

Empty Multimodul™ housing for reception of crimp contacts, for indirect mating

3111 01 L

Multimodul™ crimp contact, in bulk

3111 01 G

Multimodul™ crimp contact, on reel

3111 03 L

Multimodul™ crimp contact, in bulk

3111 03 G

Multimodul™ crimp contact, on reel

3850

Multimodul™ pin header, upright, with locking latch, with retaining hooks

3853

Multimodul™ pin header, angular, with locking latch, with retaining hooks

8385 A 01

Double Multimodul™ chassis pin header as feed-through connector, with locking latches and gasket

逐步淘汰

3851

Multimodul™ pin header, upright, with retaining hooks

逐步淘汰

3852

Multimodul™ pin header, upright, with locking latch

逐步淘汰

3855

Multimodul™ pin header, upright, with locking latch, with retaining hooks and cut-outs for 3801

逐步淘汰

3800

Multimodul™ socket board, angular, with retaining hooks

逐步淘汰

3801

Multimodul™ socket board, angular, with retaining hooks, with locking nose

系列 41 | 短接型连接器，间距2.5/2.54mm

适用于两个插针的直接连接，即替代电路的跳线。短接型连接器适用于间距为2.5mm和2.54mm的排针。可用于信号和最高5A的负载电流。

注意 RoHS/REACH

未找到该配置的产品。

4143 01

Shorting link, with test pick-up and handle latch

系列 51 | 插卡用直接连接器，间距2.54/5.08mm

插卡用插座板，可用于信号和最高5A的低负载电流，间距为2.54mm和5.08mm。

注意 RoHS/REACH

未找到该配置的产品。

5116

Socket board for direct mating, with solder pins
contact pitch 2.54 mm

8514 A 03

Socket board for direct mating
contact pitch 5.08 mm

8514 A 01

Socket board for direct mating, with keying rib
contact pitch 5.08 mm

8514 A 02

Socket board for direct mating, with keying rib
contact pitch 5.08 mm

系列 52 | 带螺丝锁紧的直接连接器，用于插卡，间距5.0mm

用于插卡的插座板，带线对板连接用螺丝锁紧。带键控插件，安装和导槽。用于信号和最高5 A的负载电流，间距为5.0mm。

注意 RoHS/REACH

未找到该配置的产品。

5 RS

Socket board for direct mating with screw terminals, lift clamp without protection against misplacing, with test hole, consecutive placement without loss of pitch

5 RS FK

Socket board for direct mating with screw terminals, lift clamp without protection against misplacing, with test hole and mounted pair of flanges FK

逐步淘汰

SP 4

Keying insert for socket boards with screw terminals 5 RS and 5 RS FK

系列 61 | 螺丝锁紧端子台，间距3.5/5.0/10.0mm

用于维护相关的所有线对板连接。导线截面积最大4.0mm²。用于信号和最高15A的负载电流，间距为3.5mm、5.0mm和10.0 mm。

注意 RoHS/REACH

尺寸请选择间距3.50 mm间距3.81 mm间距5.00 mm间距5.08 mm间距10.00 mm

功能/技术请选择导线保护器提升夹

未找到该配置的产品。

KRMC

Micro screw terminal block, clamp with wire protector, upright version, consecutive placement without loss of pitch
contact pitch 3.5 mm

KRESS

Screw terminal block, clamp with wire protector, upright version, consecutive placement without loss of pitch
contact pitch 5.0 mm

已淘汰

KRES

Screw terminal block, clamp with wire protector, upright version, with test hole, consecutive placement without loss of pitch
contact pitch 5.0 mm

KRESW

Screw terminal block, clamp with wire protector, 45° angle version, with test hole, stringable without loss of pitch
contact pitch 5.0 mm

KRESL

Screw terminal block, clamp with wire protector, right angle version, with test hole, consecutive placement without loss of pitch
contact pitch 5.0 mm

KRM

Screw terminal block, clamp with wire protector, upright version, consecutive placement without loss of pitch
contact pitch 5.0 mm

6320

Miniature screw terminal block, with lift clamp without protection against misplacing, upright version, with test hole, consecutive placement without loss of pitch
contact pitch 5.0 mm

6322

Miniature screw terminal block, with lift clamp without protection against misplacing, 35° angle version, with test hole, consecutive placement without loss of pitch
contact pitch 5.0 mm

6324

Miniature screw terminal block, with lift clamp without protection against misplacing, right angle version, with test hole, consecutive placement without loss of pitch
contact pitch 5.0 mm

KRE

Screw terminal block, with lift clamp with protection against misplacing, upright version, consecutive placement without loss of pitch
contact pitch 5.0 mm

KREG

Screw terminal block, with lift clamp with protection against misplacing, with stronger screw, upright version, consecutive placement without loss of pitch
contact pitch 5.0 mm

KRESS 03/02 - 07/04

Screw terminal block, clamp with wire protector, upright version
contact pitch 10.0 mm

KRESL 03/02 - 05/03

Screw terminal block, clamp with wire protector, right angle version
contact pitch 10.0 mm

KREN

Screw terminal block for mains supply, with lift clamp with protection against misplacing, upright version
contact pitch 10.0 mm

KRENG

Screw terminal block for mains supply, with lift clamp with protection against misplacing, with stronger screw, upright version
contact pitch 10.0 mm

系列 65 | 插座板上的可插拔螺丝锁紧接线端子，间距5.0mm

可插拔螺丝锁紧端子的小尺寸解决方案，无错配，带锁紧。导线截面积最大4.0mm²。用于信号和最高10 A的负载电流，间距为5.0mm。

注意 RoHS/REACH

未找到该配置的产品。

KS

Pluggable screw terminal block, clamp with wire protection, consecutive placement without loss of pitch, without side walls

KSC

Pluggable screw terminal block, clamp with wire protection, consecutive placement without loss of pitch, with side walls

KB

Socket board, upright, solder pins single row, consecutive placement without loss of pitch

KBQ

Socket board, upright, solder pins dual row staggered, consecutive placement without loss of pitch

KBWO

Socket board, angular, solder pins single row, consecutive placement without loss of pitch

KBW

Socket board, angular, solder pins single row, with retaining hooks for printed circuit board edge, consecutive placement without loss of pitch

系列 67 | 排针用可插拔接线端子，间距5.08 mm

绝缘刺破端子（IDT）可用于全自动组装的连接器。可与市场上的许多产品兼容配合。用于信号和最高6 A的负载电流，间距为5.08 mm。

注意 RoHS/REACH

未找到该配置的产品。

6770

Pluggable terminal block, insulation displacement technique (IDT), with locking and test hole, cable departure 90° or 180° to plugging direction, consecutive placement without loss of pitch
